AUZZO HOME MPPT Charge Controller 48V/36V/24V/12V Negative Ground Max 150V 4500W Solar Regulator Input with Backlight LCD Display fit AGM/Gel/Flooded/User,100A
❶ Negative Ground Tracer AN series MPPT Controller with tracking efficiency no less than 99.5% (MSRT) and 12V/24V/36V/48V auto identifying system voltage. Accurately recognizing and tracking of multiple power point to ensure DC/DC transfer efficiency is up to 98.6%. Real-time energy recording and statistical with Multiple load control modes
❷ Max Input Current: 60 amp; Max Input Solar Power: 1225W(12V); 2250W(24V); 3375W(36V); 4500W(48V); Max input Voltage: 150V; Auto control system to limit the charging power & current go over the rated value.Common NEGATIVE Ground and TROUBLESHOOTING function( fault LED indicator)
❸ Solar controller mppt 60a with high quality & low failure rate components of ST and Infineon and Battery temperature compensation function to ensure the controller's life.Real-time energy recording and statistical
❹ 60A mppt controller Fit 4 charging options: Sealed, Gel, Flooded and User(couldn't set Lithium).4 type load Timer:ON/OFF mode,PV&Time control mode,PV voltage control mode,Dual Time control mode
❺ RS-485 communication bus interface is available for remote meter/ PC controller and wifi box(B07KT4Y3Y7) to meet various communication requirements in different situations
